Elasticity Hot Melt Adhesive TPU Film Traceless Underwear Thermal Bonding Garment
| Place of Origin | Shenzhen,China |
|---|---|
| Brand Name | Hunter Men |
| Certification | SGS, ISO9001 |
| Model Number | HT07-40P |
| Minimum Order Quantity | 5000 meters |
| Price | Negotiable |
| Packaging Details | 100meters/Roll and PE bag package,1 rolls in Carton |
| Delivery Time | 1-15 work days |
| Payment Terms | Western Union, L/C, T/T, D/A, D/P,Alibaba，Paypal |
| Supply Ability | 300rolls per day |
Product Details
| Other Names | Hot Melt TPU Film | Main Raw Material | Polyurethane |
|---|---|---|---|
| Melt Flow Index | 35±5g/10min (Condition:190℃,2.16Kg) | Melt Point | 120℃ |
| Work Temperature | 170-190℃ | Width | 1500mm |
| Length | 100 Meters Per Roll | Usage | Garment Accessories |
| Highlight | Hot Melt Adhesive TPU Film,Garment Thermal Bonding Film,Traceless Underwear Adhesive Film |
||
Product Description
Elasticity Hot Melt Adhesive TPU Film Traceless Underwear Thermal Bonding Garment Accessories
Model Number:HT07-40P
Description:
HT07-40P is thermoplastic material, suitable for a variety of materials, it can stick to materials after one or more times melt by hot temperature,after hot melting and quickly cold speed feature make it use to various high speed production.It performs an excellent adhesion for Fabrics,Diving Fabrics,Laica,Jersey, other elastic fabrics and so on. This adhesive product possesses excellent washability and with good dry cleaning and chemical additives resistant.
Features&Usages:
It has good resilience, elasticity, heat resistance, cold resistance and water resistance.This adhesive product possesses excellent chemical additives resistant, It main used to composite elastic fabrics to produce can be used as a health-care vest, an underwear, a health-care waistband, kneepads etc.
Operate machine:iron,high-frequency machine,heat roller machine,flat-bed heat press machine or other hot composite machine.
Physical Characteristics:
| Color | Transparent | Release Liner | Double Silicone Glassine Release paper |
| Density | 1.2±0.02g/cm³ | Conventional thickness | 30mic,50mic,80mic,100mic (can be customized) |
| Melt Flow Index | 35±5g/10min | Conventional Width | 1500mm (can be customized) |
| Hardness (Shore A) | 60A | Length | 100meters(can be customized) |
| Flow Beginning Point | 120℃ | Normal Size /Rolls | 1535mm(width)*100meters(Length) (can be customized) |
Recommended Bonding Conditions:
| First Backing Operate | Second Hot Pressure Operate | ||
| Backing Temperature | 130℃-150℃ | Hot Pressure Temperature | 150℃-190℃ |
| Hot Pressing Speed | 20m/min | Hot Pressure Speed | 15m/min |
| Pressure | 0.5-1.5KG/CM² | Pressure | 0.5-1.5KG/CM² |
Note: Due to the different bonding materials have different heat-shielding performance, the operation parameters in the technical data are only for reference. The specific hot pressing temperature, pressure and time shall be adjusted according to the different bonding materials, operating equipment and process.(Please don’t use steam when you operate by flatiron.)
We support Customization:
| Width Range | 5-1500mm |
| Length Range | 100yards-1000yards per roll or as your demands |
| Thickness Range | 10MIC-300MIC |
We can tailor hot melt film as your business and demands.
Storage Conditions:
Stored in dry unopened packaging at room temperature at least 2 years.
How to use it:
Hot Melt Adhesive Film's Advantages:
1. Clean;
2. Envorentment friendly;
3. High efficiency. In the all process, just need a several seconds.
4. Safety. This product is non-solvent and haven't any hidden trouble in your production.
5. Hot melt adhesive film has better fastness than other glue which could be widely used to laminate many materials;
6. Automatic production can be cometure.
7. Portable and easy operattion
8. Reusable. At the film melting,you can use it again and again.
9. Hot melt adhesive film has good dry cleaning, washable, low-temperature resistance, high-temperature resistance and other kinds of good features;
10. Can be used as adhesives and sealants;
