Product Details:
Payment & Shipping Terms:
|
| Main Raw Material: | 100% Thermoplastic Polyurethane | Color: | Transparent |
|---|---|---|---|
| Melt Flow Index:: | 10-25g/10min（Condition:ASTMD1238-04） | Proportion: | 1.18±0.02g/cm³ |
| Hardness: | 73±2A | Melt Point: | 85±5℃ |
| Operate Temperature: | 140-160℃ | Thickness(mic): | 150mic |
| High Light: | Thermal 150mic Adhesive Film,Transparent Thermal Adhesive Film,Bonding Nylon Velcro Thermal Adhesive Film |
||
150mic Thickness Transparent Thermal Adhesive Film Roll for Bonding Nylon VELCRO With Embroidery Patches
Description:
HT07-60L is hot melt adhesive produced in film form, it can be conveniently operated by continuous or intermittent processes.It has excellent resistance to water washing,dry cleaningrepeated. It has excellent adhesion for Lycra, spandex, nylon, excellent products such as soft feel and super elastic fabric hot pressing adhesive etc.
Physical Characteristics:
| Color | Transparent | Release Liner | Double Silicone Glassine Release paper |
| Density | 1.18±0.05g/cm³ | Conventional thickness | 150mic |
| Melt Flow Index |
10-25g/10min |
Conventional Width | 5cm to 11cm |
| Hardness (Shore A) | 73±2A | Length | 100yards |
| Melt Point | 95±5℃ | Normal Size /Rolls |
100cm(width)*100yards(Length) |
Recommended Bonding Conditions:
| First Backing Operate | Second Hot Pressure Operate | ||
| Backing Temperature | 120℃-150℃ | Hot Pressure Temperature | 130℃-160℃ |
| Hot Pressing Time | 1-5seconds | Hot Pressure Time | 5-15seconds |
| Pressure | 0.6mpa | Pressure | 0.6mpa |
Note: Due to the different bonding materials have different heat-shielding performance, the operation parameters in the technical data are only for reference. The specific hot pressing temperature, pressure and time shall be adjusted according to the different bonding materials, operating equipment and process.(Please don’t use steam when you operate by flatiron.)
Operate machine :iron,high-frequency machine,heat roller machine,flat-bed heat press machine or other hot composite machine.
Applications:
HT07-60L widely applied in waterproof zipper,saamless pockets,top fly, mesh fabric lamination for sport shose,seamless sport armband,seamless underwear,TPU and leather lamination,moblie phone case, plywood,metals,reflective materials,automobile trims,Ic card sealing, PVC lamination etc.
Package&Storage:
Package:1PC/PE FILM, 100yard/roll, 2 rolls/CTN, or it's up on the customer's option
Storage:Stored in dry unopened packaging at room temperature at least 2 years.
