48CM Width Single Side Adhesive Film PET Substrate 180mic Acrylic
  • 48CM Width Single Side Adhesive Film PET Substrate 180mic Acrylic
  • 48CM Width Single Side Adhesive Film PET Substrate 180mic Acrylic
  • 48CM Width Single Side Adhesive Film PET Substrate 180mic Acrylic
Place of Origin Shenzhen,China
Brand Name Hunter Men
Certification SGS,ISO9001:2015
Model Number HT01-YM
Minimum Order Quantity 1Yards
Price Negotiable
Packaging Details by rolls or Sheets
Delivery Time 1-15days
Payment Terms Western Union, L/C, D/A, D/P, T/T,Paypal
Supply Ability 300 Rolls/ Day
Product Details
Raw Materals Acrylic Pressure Sensitive Hot Melt Film Substrate Material Release Paper Or PET
Usage Embroidery Badges And Patches Color Transparent
Thickness(mic) 180mic Width(cm) 48CM
Hot Pressing Temperature(°C) 100-150℃ Processing Time(seconds) 3-8 Seconds
High Light

48CM Width Single Side Adhesive Film

,

PET Substrate Single Side Adhesive Film

,

180mic Acrylic Self Adhesive Film
Product Description

Hot Melt Adhesive Film Single Side With Acrylic Self Adhesive Film Sheets

Description:

It is a self-adhesive hot melt film. Double-layer film structure: one layer is hot-melt adhesive (it's haven't viscosity at room temperature, it needs to be warmed and glued), and the other layer is pressure sensitive adhesive of propylene acid (self-adhesive layer have viscosity at room temperature, release paper).Self-adhesive layer can be below 140 degrees temperature without dropping glue, without losing glue property, and can be repeatedly pasted, in line with European demand indicators.



48CM Width Single Side Adhesive Film PET Substrate 180mic Acrylic 0



Applications:

Development direction and application of HT01-YM is for adhesion in embroidery patches , phone case, handcraft  and so on.

48CM Width Single Side Adhesive Film PET Substrate 180mic Acrylic 1



Physical Characteristics:



Color Transparent Release liner Glassine release paper
Density 1.2±0.02g/cm³ Conventional Thickness 180mic
Melting point 65-85 (Hunter-men) Width 48cm
Melt Flow Index 75±15g/10min (ASTM D1238-04) Length 100yards
Operating Temperature 93-116℃ (Hunter-men) Finished Products 48cm*100yards
Lamination
Mechanical Mold Temperature 100℃-130℃
Hot Pressing Time 3-5 seconds
Rheological temperature 0.3-0.6mpa































Remarks:The above information and technical support are based on our current knowledgeand experience.They are witout guarantee and legal claim.To obtain the best processing conditions, we suggest customers test the samples before using our products



Package & Storage:

Packaging 1PC/PE FILM, 100meters/roll, 1 rolls/CTN, or it's up on the customer's option
Storage Conditions Stored in dry unopened packaging at room temperature at least 2 years.





Support Customization Production:



We have many years experience for control the products quality, and we can customize to product as your opinions.According to customer details demands for new product development, we can offer technical support and production as customer opines.Please contact with us for any about the product questions.



1. According to the Film Performance:



Melt Point: 70-110℃,

Melt Index:10-2000g/10min( Condition:190℃/2.16KG ASTMD1238-04),

Thickness:0.05mm-1mm,

Width: 5mm-1500mm,

Length:1M-1000M/roll,

Colors:All of colors



2. According to the base material:



A. Single/Double side silicone glassine release paper,

B. Single/Double side silicone kraft release paper,

C. Single/Double side silicone PE coated paper,

D. Matte / Glossy PP paper,

E. Matte / Glossy Pearlescent paper,

F. Single/Double side silicone PET release film,

G. Without base materials

H. You also can choose the base materials thickness and grammage.



3.Custom Punching Hot Melt Adhesive Film(Support custom as your demands.)

A.Conventional Aperture:1.4mm,1.5mm,1.8mm

B.Conventional Hole Spacing:5mm*5mm or 5.8mm*3.7mm

Milky Translucent 0.03mm Thickness Polyurethane Hot Melt Glue Film For Composite Leater or Textlie Fabrics 11

We can tailor hot melt film as your business and demands.



Contact Me:
Lily

What'sapp: +8615817445470

Wechat: +8615817445470

Tel: +8615817445470

Email: lily@szhotmelt.com



If you have any other questions, please tell us soon, and we will try our best to offer our better service and products for you.
