0.98g/Cm3 Embroidery Patch Backing Glue EAA Thermal Adhesive Film
| Place of Origin | Shenzhen,Guangdong Province,China |
|---|---|
| Brand Name | Hunter Men |
| Certification | SGS，ISO9001 |
| Model Number | HT01-20A |
| Minimum Order Quantity | 50 rolls |
| Price | Negotiable |
| Packaging Details | 100 Yards in roll, 2 rolls in case |
| Delivery Time | 3-7 work days |
| Payment Terms | Western Union, L/C, T/T, D/A, D/P,Alibaba，Paypal |
| Supply Ability | 300rolls per day |
Product Details
| Structure | EAA Film + Glassine Release Paper | Liquidity Index | 60-95g/10min (ASTM D1238-04) |
|---|---|---|---|
| Proportion | 0.98g/cm³ | Melt Point | 80-100℃ |
| Width(mm) | 96cm | Packing | 100 Yards Per Roll |
| Washable Test | 40℃/72H | Color | Clear |
| High Light | 0.98g/Cm3 Embroidery Patch Backing Glue,EAA Thermal Adhesive Film,0.98g/Cm3 Thermal Adhesive Film |
||
Product Description
EAA Clear 0.98g/cm3 100cm width Hot Melt Glue Film For Embroidery Patch
Description:
Hunter-MEN HT01-20A(Po hot melt adhesive film) is a double-layer structure (release paper +hot melt adhesive film)products, it have excellent stickiness for textiles,metals and other materials,the features are non-elastic,washable, transparent and environmentally,so it’s widely used to clothing logos industries.
Physical Characteristics:
| Color | Clear | Release Liner | Release paper |
| Density | 0.98g/cm³ | Conventional thickness | 60mic,80mic,100mic,120mic,150mic,180mic |
| Melt Flow Index |
50±20g/10min ASTMD1238-04 |
Conventional Width | 5MM-1500MM |
| operating Temperature | 120℃-170℃ | Length | 100yards |
Recommended Bonding Conditions:
| First Backing | Second Hot Pressure | ||
| Mechanical Mold Temperature | 120℃-150℃ | Mechanical Mold Temperature | 140℃-170℃ |
| Hot Pressing Time | 3-5seconds | Hot Pressing Time | 5-20seconds |
| Pressure | 0.6mpa | Pressure | 0.6mpa |
Applications:
Hunter-MEN HT01-20A is for adhesion in garments accessories, footwear, handbags, luggage, embroidery, hot fix and crafts and so on.It's mainly used for packaging paper,carpet,aluminium-plastic panel,embroidery patch.
HOW TO USE:
Hot melt adhesive film have 2 layers(release paper +hot melt adhesive film)
1. Put hot melt adhesive film on the bonding material A, and release paper layer is up, hot melt adhesive film layer is down,the sequence: release paper +hot melt adhesive film+material A
2.Put release paper +hot melt adhesive film+material A in hot pressure machine,and hot pressing on the release paper side
3.After that cooling, peel out the release paper
4.Put material B on the hot melt adhesive film,,the sequence: material A+hot melt adhesive film+material B, then hot pressing again
Note: Due to the different bonding materials have different heat-shielding performance, the operation parameters in the technical data are only for reference. The specific hot pressing temperature, pressure and time shall be adjusted according to the different bonding materials, operating equipment and process.(Please don’t use steam when you operate by flatiron.)
|
Other Hot Melt Glue Film For Embroidery Patch |
||||
| Type | HT03 | HT01-2000 | HT01-4000 | HT05 |
| Color | Milky White | Transparent | Transparent | Transparent |
| Bottom Materials | Single Silicon Glassine Release Paper | |||
| Melt Point(℃) | 108 | 85 | 80 | 100 |
| Pressing Temperature(℃) | 120-160 | 110-150 | 100-140 | 120-160 |
| Adhesive Strengh(N/1c㎡) | >80 | >80 | >80 | >80 |
| Normal Thickness | 0.06mm,0.08mm,0.1mm, 0.12mm,0.15mm | |||
| Dry Cleaning | * | NO | NO | *** |
| Washable | ||||
| 40(℃) | *** | *** | *** | *** |
| 60(℃) | ** | * | NO | ** |
| 80(℃) | * | NO | NO | * |
Customer Feedback
Package
Delivery Date: 1-7days after confirmed the samples and received the payment
Package:1PC/PE FILM, 100yard/roll, 2roll/CTN, or it's up on the customer's option.
Why Choose Us:
1, more than 10 years experience in production.
2, well-known products: Sichuan Famous Brand.
3, Good quality control in production process: Quality Service AAA Grade Credit Enterprise
4, Excellent quality and Competitive price, OEM is available.
5, Stable supply: an extensive range of stock.
6, The whole process from material to end products is under supervision.
Our Service:
1, Your inquiry will be replied within 24 hours and online service is available all the time.
2, Well-trained & professional sales persons are here ready to answer all your questions and handle the problems.
3, Prompt delivery time: within 15 days after agreement
4, Flexible payment terms: T/T, L/C, O/A, Western Union, Paypal, Escrow, etc.
5, Your business relationship with us will be confidential to any third party.
6, Good after-sale service offered, please get back if you got question
If you have any other questions, please tell us soon, and we will try our best to offer our better service and products for you.
