0.18mm Thickness Hot Acrylic Pressure Sensitive Film Self Adhesive
| Place of Origin | Guangdong, China |
|---|---|
| Brand Name | Hunter Men |
| Certification | SGS,ISO9001 |
| Model Number | HT01-4000 |
| Minimum Order Quantity | 1 rolls |
| Price | Negotiable |
| Packaging Details | 2 rolls /carton, 1 PE bags/rolls or as you demands. |
| Delivery Time | 5-7days |
| Payment Terms | Western Union, L/C, D/A, D/P, T/T,Paypal |
| Supply Ability | 300 Rolls/ Day |
Product Details
| Color | Transparent | Melting Point(°C) | 80℃ |
|---|---|---|---|
| Hot Pressing Temperature(°C) | 100-130℃ | Brand | Hunter Men |
| Substrate Material | Release Paper | Processing Time(seconds) | 5-15 Seconds |
| Thickness (mm) | 0.18MM | Width(mm) | 100CM |
| Port | Shenzhen | Material | PO+Acrylic |
| Product Name | Hot Acrylic Pressure Sensitive Film | Application | Embroidery Patches Or Handcraft |
| Feature | Movable And Residue Free | Packing | 2 Rolls /carton, 1 PE Bags/rolls Or As You Demands. |
| High Light | Hot Acrylic Pressure Sensitive Film,0.18mm Thickness Pressure Sensitive Film,0.18mm Thickness glue film adhesive |
||
Product Description
0.18mm Thickness Hot Acrylic Pressure Sensitive Film for Embroidery Patches
Description:
HT01-2000YM is a self-adhesive hot melt film. Two layers film structure: the one layer is hot melt adhesive film(it's haven't viscosity at room temperature, after hot pressure will have stickness), and another layer is sensitive adhesive (self-adhesive layer have viscosity at room temperature).Self-adhesive layer can be below 120 degrees temperature without dropping glue, without losing glue property, and can movable.
Applications:
HT01-2000YM is widely used in embroidery patches and handcraft lines.
Other Application:
Physical Characteristics:
| Color | Transparent | Release liner | Glassine release paper |
| Density | 1.2±0.02g/cm³ | Conventional Thickness | 0.18mm |
| Melting point | 85±5℃ (Hunter-men) | Width | 6mm-1000mm |
| Melt Flow Index | 200±15g/10min (ASTM D1238-04) | Length | 1000mm |
| Operating Temperature | 100-130℃ (Hunter-men) | Finished Products | 480mm*100yard |
| Lamination | |||
| Mechanical Mold Temperature | 100℃-130℃ | ||
| Hot Pressing Time | 3-5 seconds | ||
| Rheological temperature | 0.3-0.6mpa | ||
1, Bonding temperature and pressure as well as the time involved in the strength of the film to material. Bonding temperature must be close to the machine set the temperature, the pressure must be uniform, mold and pressure roller must be flat.
2, In different machinery and materials, the bonding conditions used will be different. The conditions marked here are only basic. The optimum bonding conditions should be made by creating suitable construction conditions for the particular application damage, direct or consequential, arising out of the use, misuse or inability to use the product.
NOTICE: Seller hereby excludes any express warranties and the implied warranties of merchantability and fitness for a particular purpose. The following is made in lieu of any such warranties. Tunsing believes the information supplied are reliable, but does not guarantee that any results shown or claimed will be obtained. Before using the user shall determine the suitability and fitness of the product for its intended use. The user assumes all risks and liability whatever in connection with its own tests and use. Neither seller nor manufacturer shall be liable for any injury, loss or damage, direct or consequential, arising out of the use, misuse or inability to use the product.
Packing:
1PC/PE FILM, 100Yard/roll, 1~4rolls/CTN, or it's up on your option
 |
 |
|
|
Hot Melt Adhesive Film's Advantages
1. Clean;
2. Envorentment friendly;
3. High efficiency. In the all process, just need a several seconds.
4. Safety. This product is non-solvent and haven't any hidden trouble in your production.
5. Hot melt adhesive film has better fastness than other glue which could be widely used to laminate many materials;
6. Automatic production can be cometure.
7. Portable and easy operattion
8. Reusable. At the film melting,you can use it again and again.
9. Hot melt adhesive film has good dry cleaning, washable, low-temperature resistance, high-temperature resistance and other kinds of good features;
10. Can be used as adhesives and sealants;
1. Clean;
2. Envorentment friendly;
3. High efficiency. In the all process, just need a several seconds.
4. Safety. This product is non-solvent and haven't any hidden trouble in your production.
5. Hot melt adhesive film has better fastness than other glue which could be widely used to laminate many materials;
6. Automatic production can be cometure.
7. Portable and easy operattion
8. Reusable. At the film melting,you can use it again and again.
9. Hot melt adhesive film has good dry cleaning, washable, low-temperature resistance, high-temperature resistance and other kinds of good features;
10. Can be used as adhesives and sealants;
Why Choose Us
1, more than 10 years experience in production.
2, well-known products: Sichuan Famous Brand.
3, Good quality control in production process: Quality Service AAA Grade Credit Enterprise
4, Excellent quality and Competitive price, OEM is available.
5, Stable supply: an extensive range of stock.
6, The whole process from material to end products is under supervision.
FAQ
1, Q: How will you pack the product?
A: We will use paper cartons to pack the product, usually 2 or 4 rolls per cartons,or according to your demands.
2, Q: How many rolls can be full fitted into one container, such as 20FT, 40FT?
A: According to the goods quantity and the carton's size,we will calculate for you accordingly.
3, Q: How about the adhesive of the adhesive film?
A:It is self adhesive adhesive film. We can produce one side and two sides adhesive but usually one side adhesive. Besides, the stickiness can be controlled as customized.
4, Q: How many layers of the adhesive film can your equipment make?
A: Our equipment can produce 1/2/3 layers adhesive film.
5, Q: Do you accept OEM?
A: Yes, we do.
6, Q: Do you provide free sample? And how many days it will take?
A: Yes, we provide free sample, only need you to pay the courier charge. We will make the sample within 1 working days and it will take 3-7days on the transportation.
7, Q: What's your delivery time?
A: We are factory, so we can efficiently control the production time, and then for the delivery time, it is 3-15 working days.
8, Q: What's your production capacity?
A: At present, our production capacity is 6000 rolls per month. However, we are planning to open a new factory and add more production lines.
9, Q: Can you produce colored adhesive film?
A: The film colors depend on the raw material's colors, if the quantity is big, we will make colors adhesive film for you, if you just have a small quantity, we need add some charge.
10, Q: What's your payment term?
A: We accept T/T, L/C, O/A, Western Union, Paypal, Escrow, or customized if it is acceptable.
