Double Sided 23GSM Hot Melt Adhesive Web 200 Yards/ Roll HT05-23
| Place of Origin | Shenzhen,Guangdong Province,China |
|---|---|
| Brand Name | Hunter Men |
| Certification | REACH,ROHS,ISO9001 |
| Model Number | HT05-23 |
| Minimum Order Quantity | 100 rolls |
| Price | Negotiable |
| Packaging Details | 2 or 4 rolls /CTN, 1 PE bags/rolls or it's up on your option. |
| Delivery Time | 1-15work days |
| Payment Terms | Western Union, L/C, T/T, D/A, D/P,Alibaba |
| Supply Ability | 1500rolls per Week |
Product Details
| Composition | Co-polyamide | Type | HT05-23 |
|---|---|---|---|
| Color | White | Density | 1.1±0.02g/cm³ |
| Melting Point(°C) | 115-130℃ | Gram Weight | 23G |
| Width(mm) | 1500mm | Length(Yards) | 200yards/ Roll |
| High Light | 23GSM Hot Melt Adhesive Web,Double Sided Hot Melt Adhesive Web,200 Yards/ Roll fusible bonding web |
||
Product Description
23 GSM PA Hot Mlet Glue Web Better Bond Strength Double Sided Adhesive Interlining
Composition:
Co-polyamide
Features:
The product features are good flexibility,good air-permeability,soft feeling and high stripping strength,excellent resistance to washing,environment friendly.
| Property | Criterion | |
| Appearance | White web film | |
| Composition | Copolyamide | |
| Density | 1.1±0.02g/cm3 | |
| Melting Range | 115-130℃ | |
| Bonding Conditions | Temperature | 130-140℃ |
| Pressure | 1.0-2.5kgf/cm2 | |
| Time | 10-15S | |
| Washable Property | 40℃ | Excellent |
| 60℃ | Good | |
| Dry Cleaning Performance | Excellent |
|
Specification:
| Width range | 10-3200mm |
| Length range | 100yards-500yards per roll |
| Gram Weight range | 7g-80g/㎡ |
Operate machine :iron,high-frequency machine,heat roller machine,flat-bed heat press machine or other hot composite machine.
Applications:
- Automotive lnterior(Roof/Head-liner,Seat cover,Cushion Sun Visor,Thermal &Acoustic lnsulation material,Air Filter,Carpet,etc.)
- Home Textiles(Curtains,Tablecloths,Bedspreads,Mattresses,Pillowcases,etc.)
- Garment & Luggage industry(Gloves,Bags,Fabrics,Artificial Leather,Shoe Materials,Luggage Lining,lntermediate lining and Supporting Materials,Clothing linings,Warm Wadding,Outerwear,Underwear,etc.)
- Medical Non-woven Fabrics(Surgical Gown,Caps,Masks,Mattresses,Bactericidal Curtains,Wet Towels,etc.)
- Furniture (Wood &Plywood Lamination,Cardboard,Fiber Splint,Fabric & Foam Lamination)
- Sound & Thermal lnsulation (multi-layer FRP Fabric,Metal Panel,Aluminum Foil Material,Various Foams)
- Filter Materials (Air Filter,Activated Carbon Non-woven,Activated Carbon Cotton,Activated Carbon Mask,Activated Carbon Filter,etc.)
May You Interesting:
| TPU Hot Melt Adhesive Film | ||||
| Type | HT07-66 | HT07-58 | HT08-90 | HT02-08 |
| Color | transparent | transparent | milky translucent | milky translucent |
| Bottom Materials | Double Silicon Glassine Release Paper | Single Silicon Glassine Release Paper | ||
| Melt Point(℃) | 115 | 95 | 60 | 90 |
| Melt Index | 8g/10min 190(℃)2.16kg | 30g/10min 190(℃)2.16kg | 40g/10min 190(℃)2.16kg | 20g/10min 190(℃)2.16kg |
| Shore Hardness(A) | 81 | 76 | 97 | 97 |
| Thickness(mm) | 0.03-0.3 | 0.03-0.3 | 0.03-0.3 | 0.03-0.3 |
| Width(mm) | 7-1500 | 7-1500 | 7-1500 | 7-1500 |
| Length(yd) | 100-300 | 100-300 | 100-300 | 100-300 |
| Pressing Time(S) | 5-15 | 5-15 | 5-12 | 5-12 |
| Pressing Temperature(℃) | 120-180 | 120-160 | 80-140 | 80-140 |
| Adhesive Strengh(N)1c㎡ | >60 | >70 | >80 | >80 |
| Washable | ||||
| 40(℃) | *** | *** | *** | *** |
| 60(℃) | ** | ** | * | ** |
| 80(℃) | NO | NO | NO | NO |
| Feature | very soft, good elasticity and stickiness | very soft, good elasticity and stickiness, long time non-yellowing | lower work temperature,good stickiness,widely adhesion arange. | lower work temperature,good stickiness,widely adhesion arange. |
Usage Method:
Hot Melt Adhesive Web is usually made of iron or other hot bonding equipment. The processing structure have two layers of material, three layers of materials.
| Temperature | 140℃ |
| Time | 1-10seconds |
| Pressure | 0.6mpa |
Double layers :
Three layers :
Packaging Details:
1PC/PE FILM, 200yard/roll or it's up on the customer's option
Delivery Detail:
Shipped in 3-15 days after payment
Hot Melt Adhesive Web's Advantages
1. Clean;
2. Envorentment friendly;
3. High efficiency. In the all process, just need a several seconds.
4. Safety. This product is non-solvent and haven't any hidden trouble in your production.
5. Hot melt adhesive film has better fastness than other glue which could be widely used to laminate many materials;
6. Automatic production can be cometure.
7. Portable and easy operattion
8. Reusable. At the film melting,you can use it again and again.
9. Hot melt adhesive film has good dry cleaning, washable, low-temperature resistance, high-temperature resistance and other kinds of good features;
10. Can be used as adhesives and sealants;
3. High efficiency. In the all process, just need a several seconds.
4. Safety. This product is non-solvent and haven't any hidden trouble in your production.
5. Hot melt adhesive film has better fastness than other glue which could be widely used to laminate many materials;
6. Automatic production can be cometure.
7. Portable and easy operattion
8. Reusable. At the film melting,you can use it again and again.
9. Hot melt adhesive film has good dry cleaning, washable, low-temperature resistance, high-temperature resistance and other kinds of good features;
10. Can be used as adhesives and sealants;
FAQ:
1 . How about hot melt adhesive film?
A: It is just a film, and the basic material is release paper. But the film is solid in room temperature, when reach its melt point,it is able to bond other materials, Different materials of hot melt adhesive film have different performances and different usages, we need understand your demands,then recommend you right products to you.
2. Do you accept OEM or ODM?
Yes ,we accept OEM and ODM,we are professional heat transfer material manufacturer ,having more than 10years experience.able to assist you R&D new products. So if you need bonding some special materials, please don’t hesitate to let us konw.
3. How do you transport the products?
If you are not urgent, we usually transport by ship because it is the cheapest way. But for the West Asia area,
we deliver by train because there is no sea to ship. And for samples and urgent cargo, we transport it by air as it is the fastest way.Of course if you have other better idea about transport, we will accept it.
4. May I have your samples?
If you need some sample for reference,please let us know your fully address/ship
mode with courier,and we will arrange sample for your reference.
5. How long is the lead time?
Sample lead time:3-7 days
Bulk lead time:7-10 days(depends on order quantity)
6. How do I pay for my order?
We accept L/C ,T/T ,Western Union , Paypal
Support Customization Production:
We have many years experience for control the products quality, and we can customize to product as your opinions.According to customer details demands for new product development, we can offer technical support and production as customer opines.Please contact with us for any about the product questions.
1. According to the Film Performance:
Melt Point: 70-110℃,
Melt Index:10-2000g/10min( Condition:190℃/2.16KG ASTMD1238-04),
Thickness:0.05mm-1mm,
Width: 5mm-1500mm,
Length:1M-1000M/roll,
Colors:All of colors
2.According to the base material:
A. Single/Double side silicone glassine release paper,
B. Single/Double side silicone kraft release paper,
C. Single/Double side silicone PE coated paper,
D. Matte / Glossy PP paper,
E. Matte / Glossy Pearlescent paper,
F. Single/Double side silicone PET release film,
G. Without base materials
H. You also can choose the base materials thickness and grammage.
We can tailor hot melt film as your business and demands.
