Payment & Shipping Terms:
|Structure:||TPU Film + Glassine Release Paper||Melt Flow Index::||10-25g/10min|
|Melt Point:||95℃||Activation Temperature:||130-160℃|
70A Polyurethane Film Adhesive,
Polyurethane Film Adhesive 25g/10 Min,
ISO9001 thermoplastic polyurethane film
Hot Melt Adheisve Film Used in Bonding Toothbrush Embroidery Patches to fabric
HT07-60L is thermoplastic material, suitable for a variety of materials, it can be heat plasticized adhesive repeated. It has excellent adhesion for Lycra, spandex, nylon, excellent products such as soft feel and super elastic fabric hot pressing adhesive etc. With super soft feel, high resilience.
Operate machine :iron,hot pressing machine or other hot composite machine.
|Color||Transparent||Release Liner||Double Silicone Glassine Release paper|
|Melt Flow Index||
|Hard (Shore A)||73±2||Length||150yards|
|Flow Beginning Point||95℃||Normal Size /Rolls||
|First Backing Operate||Second Hot Pressure Operate|
|Hot Pressing Temperature||140℃-160℃||Hot Pressing Temperature||140℃-160℃|
|Hot Pressing||1-5seconds||Hot Pressing Time||5-20 seconds|
Note: Due to the different bonding materials have different heat-shielding performance, the operation parameters in the technical data are only for reference. The specific hot pressing temperature, pressure and time shall be adjusted according to the different bonding materials, operating equipment and process.(Please don’t use steam when you operate by flatiron.)
HT07-60L can be used in the back of the toothbrush embroidery patches, in order to prevent broken embroidry thread lead to demaged embroidery patches patches.
May You Interesting:
|Hot Melt Adhesive Film for Embriodery Patches|
|Bottom Materials||Silicon Glassine Release Paper|
|Normal Thickness||0.06mm,0.08mm,0.1mm, 0.12mm,0.15mm|
|Normal Specification (width*length)||50cm*100YDS||48cm*100YDS||48cm*100YDS||48cm*100YDS|
Support Customization Production:
We have many years experience for control the products quality, and we can customize to product as your opinions.According to customer details demands for new product development, we can offer technical support and production as customer opines.Please contact with us for any about the product questions.
1. According to the Film Performance:
Melt Point: 70-110℃,
Melt Index:10-2000g/10min( Condition:190℃/2.16KG ASTMD1238-04),
Colors:All of colors
2.According to the base material:
A. Single/Double side silicone glassine release paper,
B. Single/Double side silicone kraft release paper,
C. Single/Double side silicone PE coated paper,
D. Matte / Glossy PP paper,
E. Matte / Glossy Pearlescent paper,
F. Single/Double side silicone PET release film,
G. Without base materials
H. You also can choose the base materials thickness and grammage.
We can tailor hot melt film as your business and demands.
Contact Person: Lily
