1.2g/Cm3 Hot Melt Glue Film 100 Yard / Roll Glue Film Adhesive
| Place of Origin | Shenzhen |
|---|---|
| Brand Name | Hunter Men |
| Certification | SGS,ISO9001:2015 |
| Model Number | HT01-4000YM |
| Minimum Order Quantity | 100 Yard/Yards |
| Price | Negotiable |
| Packaging Details | 2 rolls /carton, 1 PE bags/rolls or as you demands. |
| Delivery Time | 5-7days |
| Payment Terms | Western Union, L/C, D/A, D/P, T/T,Paypal |
| Supply Ability | 300 Rolls/ Day |
Product Details
| Port | Shenzhen | Raw Materals | Acrylic Pressure Sensitive Hot Melt Film |
|---|---|---|---|
| Substrate Material | Release Paper Or Release Paper | Color | Transparent |
| Thickness (mm) | 0.28MM | Width(mm) | 100CM |
| Hot Pressing Temperature(°C) | 100-130℃ | Processing Time(seconds) | 3-8 Seconds |
| High Light | 1.2g/Cm3 Hot Melt Glue Film,100 Yard / Roll Glue Film Adhesive,1.2g/Cm3 Glue Film Adhesive |
||
Product Description
Acrylic Pressure Sensitive Hot Melt Film for Earphone Case in Room Tempareture
Model Number:HT01-4000YM
Description:
HT01-4000YM is a self-adhesive hot melt film.Double-layer film structure: one layer is hot-melt adhesive (it's haven't viscosity at room temperature, it needs to be warmed and glued), and the other layer is pressure sensitive adhesive of propylene acid (self-adhesive layer have viscosity at room temperature, release paper).Self-adhesive layer can be below 140 degrees temperature without dropping glue, without losing glue property, and can be repeatedly pasted, in line with European demand indicators.
Applications:
Development direction and application of HT01-4000YM is for adhesion in embroidery patches , phone case, handcraft and so on.
Physical Characteristics:
| Color | Transparent | Release liner | Glassine release paper |
| Density | 1.2±0.02g/cm³ | Conventional Thickness | 0.28mm |
| Melting point | 65-85 (Hunter-men) | Width | 6mm-1000mm |
| Melt Flow Index | 75±15g/10min (ASTM D1238-04) | Length | 1000mm |
| Operating Temperature | 93-116℃ (Hunter-men) | Finished Products | 1000mm*100yard |
| Lamination | |||
| Mechanical Mold Temperature | 100℃-130℃ | ||
| Hot Pressing Time | 3-5 seconds | ||
| Rheological temperature | 0.3-0.6mpa | ||
Remarks:The above information and technical support are based on our current knowledgeand experience.They are witout guarantee and legal claim.To obtain the best processing conditions, we suggest customers test the samples before using our products
Package & Storage:
| Packaging | 1PC/PE FILM, 100meters/roll, 1 rolls/CTN, or it's up on the customer's option |
| Storage Conditions | Stored in dry unopened packaging at room temperature at least 2 years. |
Support Customization Production:
We have many years experience for control the products quality, and we can customize to product as your opinions.According to customer details demands for new product development, we can offer technical support and production as customer opines.Please contact with us for any about the product questions.
1. According to the Film Performance:
Melt Point: 70-110℃,
Melt Index:10-2000g/10min( Condition:190℃/2.16KG ASTMD1238-04),
Thickness:0.05mm-1mm,
Width: 5mm-1500mm,
Length:1M-1000M/roll,
Colors:All of colors
2. According to the base material:
A. Single/Double side silicone glassine release paper,
B. Single/Double side silicone kraft release paper,
C. Single/Double side silicone PE coated paper,
D. Matte / Glossy PP paper,
E. Matte / Glossy Pearlescent paper,
F. Single/Double side silicone PET release film,
G. Without base materials
H. You also can choose the base materials thickness and grammage.
3.Custom Punching Hot Melt Adhesive Film(Support custom as your demands.)
A.Conventional Aperture:1.4mm,1.5mm,1.8mm
B.Conventional Hole Spacing:5mm*5mm or 5.8mm*3.7mm
We can tailor hot melt film as your business and demands.
Why Choose Us:
1, more than 10 years experience in production.
2, well-known products: Sichuan Famous Brand.
3, Good quality control in production process: Quality Service AAA Grade Credit Enterprise
4, Excellent quality and Competitive price, OEM is available.
5, Stable supply: an extensive range of stock.
6, The whole process from material to end products is under supervision.
FAQ:
Q1) . What is hot melt adhesive film?
A: It is just a film, and the basic material is release paper. But the film is solid in room temperature, when reach its melt point, it is able to bond other materials, Different materials of hot melt adhesive film have different performances and different usages, we need understand your products needs, then recommend you right products.
Q2).Do you accept OEM or ODM?
Yes ,we accept OEM and ODM, we are professional heat transfer material manufacturer ,having more than 10years domestic sale experience, we are able to assist you R&D new products. So if you need bonding some special materials, please don’t hesitate to let us know.
Q3).How do you ship the products?
If you are not urgent, we usually transport by sea in large quantity, which is the cheapest shipping way. And for samples and urgent cargo, we transport it by air or by express, as it is the fastest way etc.
Q4). Do you provide free sample? And how many days it will take?
Yes, of course.we provide free 3-5Y sample for your testing only need you to pay the shipping cost. We will make the sample within 3 working days and it will take 3-7days on the transportation., then you will have more confidence in our product quality and service.
Q5). How long is the lead time?
Sample lead time: 1-3 days.
Bulk lead time: 7-20days(depends on order quantity).
Q6). How do I pay for my order?
We usually accept L/C ,T/T ,Western Union , Paypal.
